HTML Element Properties

HTML Element Properties display HTML-specific editable fields that allow you to monitor and change scripts.

Table 3. HTML-specific editable fields
Instruction	Value	Description	Editable
Element Name	Text	The HTML name of the element being viewed.	Yes. Click inside the property value to edit.
ID	Text	The HTML ID of the element being viewed.	Yes. Click inside the property value to edit.
Inner Text	Text	The inner text of the element.	Yes. Click inside the property value to edit.
Inner Text Index	Index of the inner text.	If multiple elements on the page contain the same text, this specifies which one is the target element.	Yes. Click inside to display a spinner and select the desired ID.
Java Script Matching Algorithm	Algorithm	The Java Script executed to find the target element.	Yes. Click inside the property value to display the Java Script Editor.
Match Hierarchy	Text	The order that the elements on a page are searched to find the target of the action.	Yes. Click inside to edit.
Reference Frame	Name of browser frame window	The object location within a frame. The Foglight Transaction Recorder uses two methods to refer to a particular frame in a frameset by its name or by its index number. When viewing the Properties window, Top or _top refers to the window object of the page at the top of the frame hierarchy. The top window has an index of zero. All other frame index numbers are generated by the browser in the order that the frames are defined in the HTML, beginning at one. Frames use the name="FrameName" attribute in the <frame ...> tag. If no reference frame displays in the properties list, _top is implied.	Yes. Click inside the property value to edit.
Reference ID	Numerical value	The Reference ID is a zero based index of the specified tag name within the page. The numbers are assigned sequentially, starting with zero, in the order they appear on the page.	Yes. Click inside the property value to display a spinner and edit the Reference ID.
Tag Name	Text	The HTML tag name of the element being viewed.	Yes. Click inside the property value to edit.
X	Numeric value	The X (horizontal) coordinate of the element being viewed in relation to the Main Window.	Yes. Click inside the property value to edit.
Y	Numeric value	The Y (vertical) coordinate of the element being viewed in relation to the Main Window.	Yes. Click inside the property value to edit.

Main window

The Foglight Transaction Recorder main window has three functions:

•

During recording, the Main Window acts like a common Internet browser. The user interacts with the Web pages in this window and each of their actions are recorded.

•

During playback, the Main Window looks like an Internet browser, but its actions are driven by the application being recorded. Each action that the user took during recording is performed by the application.

•

When not recording or playing back a script, the Main Window provides detailed results from the last time the script ran. Tables and charts show timing details, network traffic, and other useful metrics.

Results window

The Results Window displays real-time information while a script is being played.

The data is displayed on three tabs:

•

•

•

Output

The Output Tab shows diagnostic and trace information reported by the application during the execution of the script.

Figure 32. Results window - Output tab
