Using the Asset Management Dashboard

Using the Asset Management Dashboard

About the Asset Management Dashboard widgets
Customize the Asset Management Dashboard

The Asset Management Dashboard provides an overview of managed assets for the selected organization (if applicable), or the appliance.

If the Organization component is enabled on the appliance, and you are logged in to the Administrator Console (http://appliance_hostname/admin), the Asset Management Dashboard shows information for the selected organization. When you are logged in to the System Administration Console (http://appliance_hostname/system), the Asset Management Dashboard shows information for the appliance, including all organizations.

Tip:

TIP: The appliance updates the summary widgets periodically. To update most of the widgets any time, click the Refresh button in the upper right of the page: . To update most individual widgets, hover over the widget, then click the Refresh button above the widget. Some widgets may require additional steps.

About the Asset Management Dashboard widgets

About the Asset Management Dashboard widgets

Asset Management Dashboard widgets provide overviews of managed assets for the organization or appliance, as selected.

This section describes the widgets available on the Asset Management Dashboard. If the Organization component is enabled on your appliance, widgets show the information for the selected organization at the Admin level and for the appliance at the System level.

This dashboard provides a high-level overview of your asset usage. Use it to quickly review the state of your assets and look for any indicators that can improve your asset configuration. For example, you can focus on how your software licenses are used and identify which software titles need to have their license renewed.

Widget

Description

Assets By Type

This widget shows a donut chart, where each section of the chart indicates the percentage of your assets by their asset type, such as device, software, location, license, and others. Hovering over each section of the chart displays the percentage of the assets of the selected type.

Assets By Status

This widget shows a donut chart, where each section of the chart indicates the percentage of your assets by their status, such as Active, Disposed, Missing, or other. Hovering over each section of the chart displays the percentage of the assets in the selected status.

Cost ($) of Unused Licenses By Product

This widget shows a bar chart, where each bar represents the cost of unused licenses for each product. You can use this information to reassign or cancel unused licenses, and to redirect your resource where they are most needed.

License Compliance

If you have created License assets for software, this widget shows the number of Agent-managed devices that have a particular licensed software installed, and the number of licenses available. If the Organization component is enabled on your appliance, the widget shows the information for the selected organization.

License assets can be created for applications listed on the Software page and the Software Catalog page, and the license mode for applications must be Unit License or Enterprise for license information to appear on this widget. Applications with other license modes, such as Shareware, Freeware, or Not Specified, are not displayed on this widget.

This widget is for information only, and the appliance does not enforce license compliance. For example, the appliance does not prevent software from being installed on Agent-managed devices if a license is expired or otherwise out of compliance.

The following colors indicate threshold levels:

•
Red: Usage is at or above the critical threshold setting.
•
Orange: Usage is at or above the warning threshold setting but below the critical threshold setting.
•
Green: Usage is below the warning threshold setting.

To change the threshold levels, see Configure appliance General Settings without the Organization component.

For information about managing License assets, see Managing inventory.

Software Titles

This widget displays the software titles defined in the Software Catalog, with the highest number of installations on managed devices. If the Organization component is enabled on your appliance, the widget shows the information for the selected organization.

Software Publishers

This widget displays the publishers defined in the Software Catalog, with the highest number of software titles installed on managed devices. If the Organization component is enabled on your appliance, the widget shows the information for the selected organization.

Assets by Location

This widget shows a donut chart, where each section of the chart indicates the percentage of your assets by their location. Hovering over each section of the chart displays the percentage of the assets in the selected location.

Software Installed But Not Used in 60 Days

This widget shows a bar chart, where each bar represents a software title and the corresponding number of instances of that product that have not been in use in the last 60 days. You can use this information to further investigate whether these titles are needed, to reassign or uninstall unused software, and to redirect your resource where they are most needed.

Expiring Software License Maintenance

This widget shows a vertical bar chart, where each bar represents the number of software licenses that are about expire in the given time period.

Expired Software License Maintenance

This widget shows a donut chart representing the ration of expired and current licenses. Hovering over each section of the chart displays the percentage of the software licenses that are either expired or current, as selected.

Expiring Contracts

This widget shows a vertical bar chart, where each bar represents the number of contracts that are about expire in the given time period.

Expired Contracts

This widget shows a donut chart representing the ration of expired and current contracts. Hovering over each section of the chart displays the percentage of the contracts that are either expired or current, as selected.

Software License Configuration

If you set up License assets for software, and specify the license type, such as site, subscription, or unit, that information is displayed in this widget. If the Organization component is enabled on your appliance, the widget shows the information for the selected organization.

Customize the Asset Management Dashboard

Customize the Asset Management Dashboard

You can customize the Asset Management Dashboard to show or hide widgets as needed.

1.
Go to the Asset Management Dashboard.
a.
Log in to the appliance Administrator Console, https://appliance_hostname/admin. Or, if the Show organization menu in admin header option is enabled in the appliance General Settings, select an organization in the drop-down list in the top-right corner of the page next to the login information.
b.
On the left navigation bar, click Asset Management, then click Dashboard.
2.
Hover over the widget, then use any of the following buttons:
◦
: Refresh the information in the widget.
◦
: Display information about the widget.
◦
: Remove the widget.
◦
: Resize the widget.
◦
: Drag the widget to a different position on the page.
3.
Click the Customize button in the top-right corner of the page to view available widgets.
4.
To show a widget that is currently hidden, click Install.

About managing assets

About managing assets

How asset information differs from inventory information
Identifying the assets to track
View assets and search for asset information
Add barcodes to assets
Change device owners
View and configure asset lifecycle settings

Assets are the entities that contain information about the devices, software, licenses, and other items you want to manage. Assets are based on Asset Types, which are templates used to create assets.
