On Demand Migration Current - Active Directory Express User Guide

Additional Info

Architecture

The first step towards success on a project using Migration for Active Directory Express is to understand the product architecture and how this architecture will operate in your environment.

Migration for Active Directory Express consists of the following components:

  • A directory synchronization engine

  • A REST based web service

  • A management interface

  • A lightweight agent for workstations and member servers

The directory synchronization engine, the web service, and the management interface will all access the same SQL database. In most scenarios, these components will be installed on the same system. In larger or more complex network environments, the components can be distributed across multiple systems.

User workstations, member servers and computers are collectively referred to as Devices in Migration for Active Directory Express. Computers communicate with the Migration for Active Directory Express web service using the Active Directory Agent. The Active Directory Agent is a lightweight application that installs as a service on Windows computers.

To ensure that no firewall exceptions are required, the web service does not “call” the Devices to be migrated. Instead, the Active Directory Agents contact the web service at defined polling intervals, using standard HTTPS or HTTP requests to collect jobs. Jobs include key tasks such as system discovery, updating the operating system, file system, and user profile permissions, and migrating the computer to the new domain.



Standard Configuration

In the Standard Configuration for Migration for Active Directory Express, the Agent is deployed to each Device to be migrated. Those Agents communicate outbound to the Active Directory webserver in Azure over ports 80/443 every 4 hours, when a job is available, or when initially registering. They also communicate outbound to the Active Directory Agent job availability cache in Azure over UDP on port 3030 every 2 minutes.

Standard Configuration



Web Proxy Configuration

In the Web Proxy Configuration for Migration for Active Directory Express, the Agent is deployed to each Device to be migrated and use of a web proxy is enabled. Those Agents communicate outbound through the defined proxy port to the Active Directory webserver in Azure over port 443 every 4 hours, when a job is available, or when initially registering. They also communicate outbound through the defined proxy port to the Active Directory Agent job availability cache in Azure on port 80 every 2 minutes.

Web Proxy Configuration

Troubleshooting

  • Problem: A workstation that has been successfully cutover no longer responds to any additional jobs, such as Cleanup.

    Solution: If a workstation that has been successfully cutover now fails to respond to any additional jobs, such as Cleanup, check the Application event log. If you see a "The remote name could not be resolved" error, this most likely means that the SRV record for the Migration for Active Directory Express Server can no longer be resolved due to a DNS lookup failure.

    If you cannot "Ping" the Migration for Active Directory Express server from any other machines in the target domain, then you will need to remedy this on a more global scale, such as creating a conditional forwarder on the target machines' current DNS server pointing to the appropriate location.

    If you are able to "Ping" the Migration for Active Directory Express server, then check the Network Profile that was used during the Cutover to verify that the DNS settings were correct in that profile.

Cutover Job Result Codes

Result Code Error Rollback Possible
1 Unidentified Error - PowerShell Command Error No
2 Source Domain could not be contacted No
4 Bad Source Credentials No
8 Target Domain could not be contacted No
16 Bad Target Credentials No
32 Target DNS Server could not be contacted or could not resolve the target DNS domain No
64 Change Obtain DNS by DHCP
128 Set DNS Server IPs
256 Set WINS Servers
512 Register NIC with DNS
1024 Clear DNS Suffix Search List / Set to use NIC
2048 Set Alternate DNS Suffix List
4096 Enable Dynamic DNS Registration
8192 Set NIC Specific DNS Suffix
16384 Domain Disjoin Failed
32768 Domain Join Failed
65536 Source domain name does not match the system's domain No
131072 Computer Reboot failed
262144 Target Domain Name could not be resolved via existing DNS, and new DNS Servers were not provided No

Note: An odd numbered result code represents an error running the Cutover PowerShell script. The most common cause of an odd numbered result code during Cutover is that the computer either has no network card with a default gateway or more than one network card with a default gateway.

Note: Result codes are additive. There are likely multiple errors if the result code is not represented in the table.
