Configure capture and delivery

SharePlex can replicate data from one PDB to:

• another PDB in the same CDB
• a PDB in a different CDB
• a regular (non-PDB) target

SharePlex can replicate data from a regular source database to a PDB in a target Oracle CDB.

In one configuration file, you can replicate to any number of target PDBs in the same CDB or a different CDB.

To capture from a PDB

• In the configuration file, specify the TNS alias of a PDB as the datasource. For example, if the TNS alias is pdb1, the datasource specification is:

  Datasource: o.pdb1

• You can replicate from as many pluggable databases (PDBs) in the same CDB as desired: Create a separate configuration file for each PDB. Because each PDB is a different datasource, all configurations can be active at the same time.
• If replicating from more than one PDB on a system, use named export queues to separate the data streams from each one. This allows you to issue SharePlex commands that affect configurations, such as purge config or abort config, for one configuration without affecting the other configurations. For more information, see Configure named export queues

To replicate to a PDB

Specify the TNS alias of the target PDB in the routing map, as shown in the following example where pdb2 is the target:

sys02@o.pdb2

PDB configuration examples

Example 1: This example shows two configuration files, one replicating from pdb1 and the other replicating from pdb2, both replicating data to pdb3.

Datasource: o.pdb1
hr.emp    hr2.emp2    sys02@o.pdb3

Datasource: o.pdb2
sales.cust    sales2.cust2    sys02@o.pdb3



Example 2: This example shows one configuration file replicating from pdb1 to pdb2 and pdb3, both targets being on different systems.

Datasource: o.pdb1
hr.sal    hr2.sal2    sys02@o.pdb2
hr.sal    hr3.sal3    sys03@o.pdb3
