NetVault Plug-in for Oracle 13.0 - User Guide

Introducing Quest® NetVault® Plug-in  for Oracle Defining a backup strategy Installing and removing the plug-in Configuring the plug-in Backing up data Using the Oracle Flashback Database Restoring data
Restoring and recovering data: an overview Performing User Managed restores Using advanced User Managed restore procedures Performing RMAN restores Using RMAN types of recovery in a non-RAC environment Using advanced procedures with RMAN restores
Maintaining the Recovery Catalog Using the RMAN CLI Using the plug-in with Oracle RAC Using the plug-in in a failover cluster environment Using the plug-in with Oracle Data Guard Using the plug-in with Oracle Container Databases (CDBs) and Pluggable Databases (PDBs) Troubleshooting

Deployment

Plug‑in for Oracle’s support in Data Guard environments is restricted to physical standby databases. Logical and Snapshot standby databases are not supported. A physical standby database is a transactionally consistent copy of the production database. All references to standby databases see physical standby databases.

The plug-in supports the following types of Data Guard deployments:

Single-Instance

-->

Single-Instance

Multi-Instance RAC

-->

Single-Instance

Multi-Instance RAC

-->

Multi-Instance RAC

Deploying the plug-in in a Data Guard environment requires that you install the plug-in on the Primary Database Server and at least one of Physical Standby Servers — based on the backup strategy selected. For more information on selecting a backup strategy, see Defining a deployment strategy.

Single-instance to single-instance Data Guard deployment

In a single-instance to single-instance Data Guard deployment, the plug-in is installed on both the Primary and at least one of the Standby Database Servers.

Multi-instance RAC to single-instance Data Guard deployment

In a multi-instance to single-instance Data Guard deployment, the plug-in is installed in the Primary RAC Database environment and at least one of the Standby Database Servers.

For more information on deploying the plug-in in a multi-instance RAC environment, see Defining a deployment strategy.

Multi-instance RAC to multi-instance RAC Data Guard deployment

In a multi-instance to multi-instance Data Guard deployment, the plug-in is installed in the Primary RAC Database environment and at least one of the Standby Database Servers.

For more information on deploying the plug-in in a multi-instance RAC environment, see Defining a deployment strategy.
