The Record Transformations properties allow you to transform any log message before it is sent to the Management Server. This could be used to add extra information or to remove sensitive information from a log record.

•

Record Transformations: A list of record transformations that the agents must use in conjunction with the match patterns to convert any log messages. When no transformation is specified, the log record is transmitted to the Management Server without changes.

Each entry in the list includes the following columns:

•

RegEx Record Transformation Pattern: A regular expression that the agent uses to look for specific text in the collected log record.

•

Record Transformation: The replacement text that the agent uses in the log record to be transmitted to the Management Server.

Data Collection Scheduler

The Datacenter Collection Scheduler agent properties specify the data frequency settings the agent uses to read monitored log files.

•

Collector Config: A list containing the data collectors the agent uses. Each entry in the list includes the following columns:

•

Collector Name: The name of the collector the agent uses to gather data.

•

Default Collection Interval: The number of milliseconds, seconds, minutes, hours, or days during which the agent collects data.

•

Time Unit: The time unit associated with the Default Collection Interval.

•

Fast-Mode Collection Interval: The number of milliseconds, seconds, minutes, hours, or days during which the agent collects data when working in the fast collection mode.

•

Fast-Mode Time Unit: The time unit associated with the Fast-Mode Collection Interval.

•

Fast-Mode Max Count: The maximum number of the times the agent can stay in fast collection mode.

FileLogMonitor configuration example

Scan example

This example provides the configuration settings for monitoring the FglAM log files on a UNIX® system for WARN and ERROR records. The FglAM log files are located in the /home/user/FglAM/state/default/logs folder. FglAM log records have a date at the beginning of each record that look like this:

2014-11-17 13:37:22.315 ...

This format can be set as the regular expression for the record separator.

Table 1. Configuration settings for the Scan example
Group Name	Property Name	Property Details	Value set for this example
Monitored Hosts	Hosts	Host	host.domain.com
		Host name override	(optional)
		Host Type	UNIX
		SSH Port	22
		Operation Timeout	60000
		Collect System ID
		Remote Collector Executable	(optional)
		Secure Launcher	(optional)
Log Files	Log Files	Directory	/home/user/FglAM/state/default/logs
		Filename Pattern	FglAM_*\\.log$
		File Format Name
	Patterns	RegEx Match Patterns	WARN ERROR
		Match Severity
		Tags
	Exclude Records	RegEx Record Exclude Pattern	WARN ERROR
		RegEx File Exclude Pattern	C:\temp.log \| D:\temp.txt C:\apache\logs\FglAM..log\|Test..log
		Exclude Enable
File Formats	File Formats	Name
		Max Record Size	1024
		New Line Policy	ANYCRLF
		Rollover Policy	NEW
		Record Separator RegEx	^\\d{4}-\\d{2}-\\d{2} \\d{2}:\\d{2}:\\d{2}\\.\\d{3}
		Character Set	UTF-8
		Maximum Match Count	200
		Max Processing Time(s)	120
Record Transformations	Record Transformations	RegEx Record Transformation Pattern	(optional)
		Record Transformation	(optional)
Data Collection Scheduler	Collector Config	Collector Name	(default)
		Default Collection Interval	(default)
		Time Unit	(default)
		Fast-Mode Collection Interval	(default)
		Fast-Mode Time Unit	(default)
		Fast-Mode Max Count	(default)
